Main Parameters

Please be note all the parameters below are just for reference. We provide easy & flexible customized service. Learn OEM Solution.

Additional information

Rated Voltage

Max Head


Max Flow


Inlet Diameter

Outlet Diameter


Liquid Temperature


■ Parameter

Model Rated Voltage(VDC) Opearting Voltage(VDC) Max Head(M) Max Flow(L/Min) Power(W) Noise(dB)
VP30A-0615 6 4-10 1.5 2.5 2.98 ≤29.8
VP30A-1230 12 6-18 3.0 4.0 4.35 ≤30

■ Specifications

1 Impeller Type Open impeller
2 Food Grade(Y/N) N
3 Working Fluid Temperature -10°-60°C
4 Pump Theory Centrifugal Water pump
5 Driving Motor Type DC Brushless motor
6 Ambient Temperature -11°-60°C
7 Working Medium Pure Water,coolant
8 Waterproof Class IP68
9 Working Voltage Range 6.0V-18.0V
10 Power Consumption 2.98W,4.35W
11 Noise Class form 1M distance <29.7dB /(A)
12 Working Mode Continuous
13 Working life >30,000 Hours
14 OD of Inlet 8.0 mm
15 OD of Outlet 8.0 mm
16 Product Dimension 54mm*34mm*43mm
17 Product Weight 0.07kg
18 Power Supply DC power supply, battery, solar powered
19 Remarks Not a self-priming pump

■ Graph & Dimension

vp30a bldc pump dimension
